DESCRIPTION OF THE DNC 60 PAGE 9
T
HE USER INTERFACE
THE SCREEN
The screen displays the products, and machine parameters as well as all other
useful information for programming and machine work.
The keys situated on the front of the DNC 60, are used for selecting the
screen pages and introducing data.
A cursor indicates where the user can intervene.
THE KEYBOARD
The keyboard is divided into several zones:
a) Numerical keyboard
b) Screen page selection keys
c) Working mode selection keys
d) The commands
e) The cursor keys
f) Other keys
a) Numerical keyboard:
The numerical keys as well as the
and keys are used to introduce
numbers or values into the different fields.
b) The screen page selection keys:
MENU
key
Gives access to the MAIN MENU page.
PRODUCT LIST
key
Pressing this key displays the list of products in
the DNC memory.
PRODUCT
key
Visualization of the product data (sequence 0)
and shear functions.
SEQUENCE
key
Triple function key.
Pressing the key once displays all the values of
the current sequence.
Pressing a second time displays the main values
of the sequences and axes in large characters.
Pressing a third time displays the main values
of the sequence with the secondary values of
the axes in large characters.
