THE SCREEN PAGES PAGE 33
SEQUENCE
PAGE
(
LARGE CHARACTERS
),
O
PERATING
Key .
P 0 N 1 CY__
STOPPED
M ALU1 2.00
X3
_ 100.0
99.8
1000
JS__x__/__
Q _____/_____
This page is forced as soon as entering in the cycle.
It has been made to display in which state the machine is while working.
Relating to the programming page
, we have here in particular:
! The correct axis position underneath the programmed value.
! On CY: the number of repetitions already effectuated.
! On JS__x__: the number of jump repetitions already effectuated.
! On Q: the number of products already effectuated.
