THE SCREEN PAGES
PAGE
35
O
RIGIN OF AXES
Choice 7
of the m
ain menu
This page is used to introduce or modify
the origin of the m
ain axis (X3).
PRODUCT 4 STOPPED
SET MAIN AXES
X3 100.0
100.0
!
Place the cursor on
the axis f
ield desired.
!
Program th
e chosen va
lue.
!
Then rem
ove the cursor f
rom the f
ield (
or
) to validate the
value entered.
!
This value is entered into the corresponding
-POS-
field
!
The
key allow
s to d
isplay th
e auxiliary
axes (X4/X5/X6).
42
44
Table of Contents
Safety and Maintenance Instructions
3
License Agreement for Cybelec Software
5
Table of Contents
9
Foreword
11
Description of the Numerical Control Dnc 60 Gs
13
General Information
13
Physical and Logical Organization
15
The Memories
16
Work Memory (Buffer Memory)
16
DNC Internal Memory
16
The User Interface
17
The Screen
17
The Keyboard
17
Presentation of the Screen
21
Cursor Accessible Fields
21
The Screen
23
The MENU Page
23
List of Products in the Internal Memory
24
List of Products According Criteria
25
Production Page
26
Consulting the Production Page
26
PRODUCTION Page : Explication of the Fields
27
Working Time
28
Loading and Saving an Order
28
Consulting the Orders
28
Deleting an Order
29
Introduction of Alphanumerical Characters in the Fields
29
Transfer RS232 Page
30
PRODUCT Page (AF Information)
31
PRODUCT Page
32
Sequences List Page
34
SEQUENCE Page (Small Characters)
36
Definition of the Work Cycle
39
SEQUENCE Page (Large Characters), Programming
40
SEQUENCE Page (Large Characters), Operating
41
Correction Page
42
Origin of Axes
43
Machine Parameters
44
Programming
45
Operating Procedure
45
Clearing the Buffer
45
Programming a Sequence
45
Creation of a Second (or N Th ) Sequence
46
Searching for a Sequence
46
Deleting a Sequence
46
Insertion of a Sequence
47
Jumping a Sequence
47
Sequence Repetition
47
Repeating a Group of Sequences
47
Storage and Recall of Programs in the Internal Memory
48
Storing a Product
48
Recall of a Product from the Internal Memory
48
Deletion of a Product from the Internal Memory
49
Complete Clearance of the Internal Memory
49
Modification of a Product in the Internal Memory
49
The Initialization Page
51
Transmission
53
Tests of the Serial Ports
54
Cyback
55
Protection of the Access Levels
57
General Information
57
The Users
58
Access by Password
59
Access to Levels Superior to 3
60
Change Password
61
Management of the Access Levels by External Key
62
Maintenance
63
In Case of Failure
63
Initial Checks to Carry out
63
Possible Memory Pollution
63
Before Calling for Technical Help
64
Safety and Interactive Messages
65
The Interactive Messages
65
Print Screen to the Printer (or Ascii File)
69
Index
71
