PAGE 20 USER GUIDE DNC 60 GS
WORKING TIME
The requested and realized times can be modified at all times by the operator.
Four counters allow to totalize the production times.
The time of:
PRODUCTION
corresponds to Auto mode
TOOL ADJUSTMENT
corresponds to Manual mode
PRODUCT ADJUSTMENT
corresponds to Semi-auto mode
PROGRAMMING
corresponds to Programming mode
For the times to be managed, the fields must not remain empty.
Also for the
PRODUCTION
,
TOOL ADJUSTMENT
and
PRODUCT
ADJUSTMENT
counters to turn, the machine must have been indexed.
Counting is only done if the operator has left the
PRODUCTION
page, in
order to prevent any modification during time calculation.
LOADING AND SAVING AN ORDER
If necessary clear the page by pressing the key twice.
After having filled in the chosen fields, press the
key.
The effects of this function are:
! to control that the number of orders is not greater than the foreseen
limit of 9, if so the
COMPLETE
message is displayed.
! to display the message
STORED
if the storage has been done
correctly or
LAST
if it is the biggest order number recorded. The
storage of an order with a number greater than n+1 orders already
recorded provokes the storage under the number n+1.
CONSULTING THE ORDERS
It is possible at all times to display the orders.
From the
PRODUCTION
page, the next job on the list can be displayed by
pressing the
key and the previous job by pressing the key.
This is a round robin list.
You can also designate a page number in the
PRODUCTION PAGE
field
and press the
key.
