PAGE 58 USER GUIDE DNC 60 GS
DELETED
Displayed in
mode when a product or
sequence is deleted using the
key.
DNC <
–
> PC
Indicates a transfer from a DNC towards a PC.
END
Displayed in
or mode, indicates
the last sequence of the program.
ERR-AXIS
Following error (theoretical trajectory).
ERR-MODE
In the case of a transmission exterior-DNC, this
message indicates that the data received are not
valid, and thus impossible to read.
ERROR
This message is indicated when a calculation is
impossible, or would create out-of-range values.
When security measures are in force (in other
words when an axis is told to move beyond its
authorized limits).
This information is followed by a return to
mode and the cursor positions itself
automatically over the field to be corrected.
Error LS
Limit switch error.
ErrorN2X
N2X command error.
EXECUTED
The DNC has made the calculation correctly
(corrections, transformations, etc.).
EXISTS
Displayed in
mode when the product
number chosen for storage already exists in the
cassette.
FREE
Displayed in
mode when the buffer is
empty (no sequences programmed).
FULL
Displayed in
mode when the buffer is
full. (no more space for an additional sequence).
IGNORE
Displayed when the key used cannot (must not)
be used at that time.
INDEX
Refers to
Sheet index
when the calculation of
the length is done automatically.
