CYBEX ATON Q User Manual

22
WARNING! In some cases the buckle q of the car
safety belt may be too long and reach into the belt
slots of the CYBEX Aton Q, making it difcult to
install the Aton Q securely. If this is the case please
choose another position in the car.
• Insert the lap belt k into the blue belt guides m on both
sides of the car seat.
• Pull the diagonal belt l in driving direction to tighten the
lap belt k.
• Pull the diagonal belt l behind the top end of the baby
seat.
• Bring the diagonal belt l into the blue belt slot n on the
back.
• Tighten the diagonal belt l.
NOTE! Do not twist the car belt.
WARNING! The seat belt must run through the blue
belt routing and below the unfolded Linear Side-impact
Protection.
m
l
n

CYBEX ATON Q Specifications

General

Headrest	Yes
Washing type	Machine wash
Certification	ECE R44/04
Mounting type	Seat belt
Product color	Green
Car seat group	0+ (0 - 13 kg; 0 - 18 months)
Country of origin	Germany
Belt fastening type	3-point
Placement available	Rear-facing
Maximum weight capacity	13 kg
Maximum washing temperature	30 °C
Number of headrest positions	8
Quantity	1

Weight and Dimensions

Depth	650 mm
Width	440 mm
Weight	4600 g
Height (max)	560 mm
Height (min)	390 mm
