CYBEX ATON Q User Manual

38
WARNING! The child seat must never be used
without the cover.
NOTE! Do not twist the shoulder straps.
• Open the buckle.
• Remove the shoulder pads from the shoulder belts.
• Pull the headrest cover over the headrest rim.
• Pull the shoulder belts with the buckle tongues out of
the headrest cover.
• Remove the headrest cover.
• Pull the seat cover over the seat rim.
• Pull the buckle through the seat cover.
• Now you can remove the cover part.
REMOVING THE COVER
ATTACHING THE SEAT COVER
The cover consists of 5 parts. 1 seat cover, 1 headrest
cover, 2 shoulder pads and 1 buckle pad. To remove the
cover please follow these steps:
In order to put the covers back onto the seat, proceed in
the reverse order as shown above.
NOTE! Use CYBEX Aton Q covers only!

CYBEX ATON Q Specifications

General

Headrest	Yes
Washing type	Machine wash
Certification	ECE R44/04
Mounting type	Seat belt
Product color	Green
Car seat group	0+ (0 - 13 kg; 0 - 18 months)
Country of origin	Germany
Belt fastening type	3-point
Placement available	Rear-facing
Maximum weight capacity	13 kg
Maximum washing temperature	30 °C
Number of headrest positions	8
Quantity	1

Weight and Dimensions

Depth	650 mm
Width	440 mm
Weight	4600 g
Height (max)	560 mm
Height (min)	390 mm
