CYBEX ATON Q User Manual

32
To unlock the baby seat keep the release buttons m
pressed and then lift the shell up.
CYBEX TRAVEL-SYSTEM
Please follow the instruction manual supplied with your
push chair.
In order to attach the CYBEX Aton Q please place it
against driving direction on the adapters of the CYBEX
buggy. You will hear an audible CLICK when the baby
seat is locked into the adapters.
Always double check if the baby seat is securly fastened
to the buggy.
DEMOUNTING
m

CYBEX ATON Q Specifications

General

Headrest	Yes
Washing type	Machine wash
Certification	ECE R44/04
Mounting type	Seat belt
Product color	Green
Car seat group	0+ (0 - 13 kg; 0 - 18 months)
Country of origin	Germany
Belt fastening type	3-point
Placement available	Rear-facing
Maximum weight capacity	13 kg
Maximum washing temperature	30 °C
Number of headrest positions	8
Quantity	1

Weight and Dimensions

Depth	650 mm
Width	440 mm
Weight	4600 g
Height (max)	560 mm
Height (min)	390 mm
