CYBEX ATON Q User Manual

24
WARNING! Using the (L.S.P.) device to carry or to
fasten the Aton Q is prohibited.
NOTE! When using the Aton Q on a middle position in the
vehicle, it’s prohibited to fold out the (L.S.P.) device.
NOTE! Make sure, that the L.S.P is xed with an audible
„CLICK“.
ADJUSTING THE SIDE PROTECTORS
CYBEX Aton Q is equipped with the „ Linear Side-Impact
Protection“ System (L.S.P.). This system increases the
safety of your child in case of an side impact.
Pull the L.S.P. out to the nearest door as far as possible.
The L.S.P. disposes of two positions. In case the L.S.P.
exceeds its designated space and touches the door in
its longest position, the inclined position has to be used.
This can be done by extracting the L.S.P. completely and
subsequently by pressing the interlocking button and
moving the L.S.P. into the inclined position.
In order to push back the L.S.P. into the seat press the
locking button (f) and at the same time push the L.S.P.
towards the seat.
f

CYBEX ATON Q Specifications

General

Headrest	Yes
Washing type	Machine wash
Certification	ECE R44/04
Mounting type	Seat belt
Product color	Green
Car seat group	0+ (0 - 13 kg; 0 - 18 months)
Country of origin	Germany
Belt fastening type	3-point
Placement available	Rear-facing
Maximum weight capacity	13 kg
Maximum washing temperature	30 °C
Number of headrest positions	8
Quantity	1

Weight and Dimensions

Depth	650 mm
Width	440 mm
Weight	4600 g
Height (max)	560 mm
Height (min)	390 mm
