Cybex FT 360 Functional Trainer Owner’s Manual
Assembly
Page 6-11
2. Connect upper end of each spring (refer to steps 2A - 2E, Figures 8 and 9).
A. Firmly grasp upper end of spring. See Figure 8.
B. Flex spring approximately 90 degrees. See Figure 9.
C. Slide hook outward and remove from connector. See Figure 9.
D. Set spring aside.
E. Repeat steps 2A - 2D to disconnect upper end of other spring.
Grasp spring in this area
Figure 8
Figure 9
1. Flex (bend) spring 90 degrees
2. Slide spring inward toward connector.
NOTE: Remaining portion of spring (not
shown) will be facing downward
about 90 degrees.
