Cybex FT-360S Functional Trainer Owner’s Manual
3. Removing belt (refer to steps 3A - 3C and Figure 4).
Have an assistant hold the top pulley shown in Figure 4. A.
CAUTION: If an assistant does not hold pulley while performing step 3C injury may occur.
Using a 7/32” Allen wrench, remove 2 set screws.B.
Remove belt and set belt and pulley off to side.C.
Figure 4
Pulley
Set Screws
Belt
Hold pulley to
prevent pulley
from falling
Assembly
Page 6-8
