Service
Page 8-3
1 13 08014 PULLEY ASSEMBLY - 4.50
2 2 08135 BRG, BALL
3 4 08229 P/PIN,DETENT
4 2 11040-301 CLAMP BLOCK INSERT
5 4 11040-440 KNOB
6 2 3900-438 DECAL, CYBEX
7 2 4605-323 WT ROD .625 DIA x 45.00
8 2 4700-019 BEARING, FLANGE
.62 ID. x .92 OD. x 1.50 LG
9 1 4800-255 C TOP WT 15-4 X 18
10 1 51073 HIP HARNESS
11 1 51122 ANKLE STRAP
12 1 51198 WARRANTY BOOKLET (NOT SHOWN)
13 1 54001 SIGN FACILITY SAFETY
14 1 54600 FT360 TRAINING CD ROM
15 1 9100-006 PALLET, SHIPPING
16 2 9100-204 P ARM ADJUSTMENT
17 2 9100-303 MOLDED PULLEY SWIVEL
18 2 9100-304 DECAL, ROTATIONAL POSITION 1 - 10 0
19 1 9100-311 CAP, SHROUD COVER
20 1 9100-313 DECAL, WEIGHT PLATE 1 - 25
21 2 9100-314 CYLINDER, DAMPNER
22 4 9100-315 CLIP, DAMPNER SAFETY
23 2 12220-005 HANDLE ASSEMBLY
24 2 9100-318 GRIP, 5.88 LG x 2.00 OD x 11 GA WALL
25 2 9100-343 PLATE, SPRING CABLE RETAINER
26 4 9100-353 SPACER, ARM CLEVIS
27 1 9100-365 PANEL, SHROUD FRONT
28 1 9100-367 PANEL, SHROUD END RIGHT SIDE
29 1 9100-368 PANEL, SHROUD END LEFT SIDE
30 4 9100-380 DECAL ABC POSITION
31 4 9100-381 PULLEY PIVOT PIN
32 4 9100-383 BUSHING
33 1 9100-384 PANEL, SHROUD BACK
34 1 9100-385 HINGE, .06 x 2.00 x 62.00 LONG
35 1 9101-002 CABLE S/A
36 2 9101-003 CABLE S/A
37 1 9101-200 W MAIN FRAME
38 1 9101-203 P/ BELT CLAMP POST
39 1 9101-204 P/BELT CLAMP
ITEM QTY PART NO. DESCRIPTION
9101 - FT-360S Station
40 2 9101-300 SPRING, EXTENSION 1.671 x 1.995 x
26.00 LG
41 1 9101-60 FT-360S COATED ASSY
42 2 AH020000 SWIVEL HOUSING
43 1 BH030207 PIN, WEIGHT SELECTOR
44 2 BR030206 RING, RETAINING
45 4 BR030213 RETAINING RING, 2.00 EXTERNAL
46 4 BR030214 RETAINING RING, .625 DIA
47 2 BR030224 RETAINING RING, 1.188 INTERNAL
48 4 BS070201 COM SPRING .56 x .66 1.50 LG
49 1 CC010203 BOX, RSC 10 X 6 X 12 (NOT SHOWN)
50 1 CJ000027 BUBBLE WRAP, 24 INCHES WIDE
51 1 CM000211 DECAL, PATENT PENDING
52 1 CP300200 BAG, POLY 4.00 x 4.00
53 1 CP300201 POLY BAG 9 X 12
54 2 EW000027 CABLE TIE
55 2 FB030213 ROD END BEARING FEMALE .375-24
UNF
56 4 FB130206 BEARING, FLANGE 2.00 ID. x 2.25 OD. x
1.00 LG
57 4 FB130212 BUSHING, FLANGE .75 ID x .875 OD x .75
LG
58 66.375” GB000202 BELT, .95 WIDE
59 2 GP000000 PULLEY ASSEMBLY - 4.50
60 2 GP000209 PULLEY ASSEMBLY-3.50
61 2 GQ000206 SNAP LINK
62 4 HC700415 BHSCS .375-16 X .75
63 4 HC700426 BHSCS .375-16 X 2.00
64 2 HC700428 BHSCS .375-16 X 2.25
65 4 HC702815 SHCS .375-16 X .750
66 2 HC702817 SHCS .375-16 X 1.00
67 4 HC702822 SHCS .375-16 X 1.50
68 46 HF579000 PANEL FASTNER, 10-24 U TYPE
69 4 HF700000 PANEL FASTNER, .375-16 , U TYPE
70 4 HM580410 BHSCS .190 10-32 X .375
71 4 HN-60065 NUT, HEX SELF- LOCKING .312-18 BLK
ZINC
72 6 HN704400 NUT, HEX JAM .375-16
73 24 HN704901 LOCKNUT, .375-16 NYLON
74 2 HP286715 PIN, .188 DIA x .75 ROLL
ITEM QTY PART NO. DESCRIPTION
Cybex FT-360S Functional Trainer Owner’s Manual
