75 1 HP286819 SPIRAL PIN .188 X 1.12 76 2 HP346717 ROLL PIN .375 X 1.00 77 4 HS347600 WASHER, SAE .375 78 4 HS347601 WASHER, FENDER .375 ID x 1.50 OD x .06 THK 79 2 HS407100 WASHER, SPRING .650 ID x .790 OD x .062 THK 80 4 HS-60536 BOLT, BHSC .375-16 x 2.00 BLK ZINC 81 4 HW-60085 WASHER, USS .312 BLK ZINC 82 4 HX-60184 BALL STUD, .312 - 18 UNC x 10 mm 83 2 HX-60671 CAP, PLASTIC 1.25 ID. 84 46 HX570412 BHSCS, 10-24 X .50, SS 85 4 HY662912 SET SCREW, .312 - 18 UNC x .50 WITH LOCTITE 86 4 HY740000 SET SCREW 87 2 JC700422 BHSCS .375-16 X 1.50 88 9 JC700424 BHSCS .375-16 X 1.75 89 1 JC700434 BHSCS .375-16 X 3.00 90 2 JC702850 SHCS .375-16 UNC X 5.00 91 4 JL340004 HX HD LAG SC .375 X 3.00 92 2 JN714400 NUT, HEX JAM .375-24 UNF
Cybex FT-360S Functional Trainer Owner’s Manual
ITEM QTY PART NO. DESCRIPTION
9101 FT-360S Station
Service
Page 8-4
*Language Key 1-German 2-French 3-Spanish 4-English 5-Japanese 6-Swedish 8-Russian
93 4 PP040004 BALL STOP 94 4 PP090202 INSERT, PLASTIC 1.50 x 3.00 x 11 GA 95 4 PP660009 INSERT, PLASTIC SLOT 96 2 PR060005 BUMPER, WEIGHT 97 4 PR070003 FOOT PAD, 2.00 x 5.25 98 4 PR070004 FOOT PAD, 3.00 x 5.00 99 1 PU060203 BUMPER 100 2 PW-60615 PULLEY, CABLE, 2.00 OD x 1.0 HUB 101 2 HS760106 WASHER, FLAT, 1.75 X .688 X .140 T 102 2 HY702912 SET SCREW, .375-16 x .50 103 2 9100-207 STABILIZER TUBE 104 2 9101-201 MAIN ROTATION PIVOT 105 2 9101-202 ARM 106 1 9101-598-X*PLACARD 107 1 9101-599-X*PLACARD 108 1 9100-348-X*DECAL, CAUTION 109 1 4605-381-X*DECAL, WARNING 110 4 8500-311-X*DECAL, WARNING 111 1 9101-999-X*OWNERS MANUAL (NOT SHOWN) 112 2 9100-316 GRIP HAND STRAP ASSEMBLY
ITEM QTY PART NO. DESCRIPTION
