Cybex 425T Treadmill Service Manual
Service
Page 4-37
ITEM QTY. PART NO. DESCRIPTION
NO.
75 4 HB-18768 Bearing, LF-1011-12
76 2 HS-60022 Bolt, 3/8 x 2.25, HXHD CAP, Black Zinc, G5
77 2 HN-60064 Nut, Jam 3/8 - 16, Black Zinc
78 1 AF-18481 Weldment, Motor Base
79 1 AF-18769 Bracket, Heat Sink
80 2 HB-18768 Bearing, LF-1011-12
81 1 AD-18213 PCA, Control Board,115 VAC
81 1 AD-18217 PCA, Control Board, 230 VAC
82 2 EC-18538 Circuit Breaker, 15 Amp, 115 VAC
82 2 EC-18539 Circuit Breaker, 10 Amp, 250 VAC
83 1 EC-18896 Filter, 16 Amp
84 4 HN-11136 KEPS, 5/16 - 18, HEX STL ZINC
85 8 HS-19111 Screw, SEMS, 8/32 x .38, PNHD EXT Black Zinc
86 8 EH-00986 Wire Tie, Nylon, 9
87 2 HN-11925 KEPS, 10-32, HEX STL ZN
88 1 HW-10856 Washer, Lock External, No. 10 ZC
89 2 HS-15732 Screw, SEMS, 8-32 UNC x .62, PNHD PHIL, ZN
90 1 EH-12260 Wire Tie, Nylon, 18
91 1 FS-19355 Plate, Circuit Breaker Mount
92 1 DE-16928 Label, Disconnect Power, Multilingual
93 1 DE-19238 Decal, Warning, Motor Plate
94 1 DE-19198 Decal, Cybex logo
95 1 AF-18728 Bracket, Idler
96 1 HB-19135 Idler Wheel, 1.88 x 1.0
97 2 HB-18056 Bushing, Flange, .375 x .469 x .25
98 1 HS-19338 Screw, 3/8 - 16 x 1.75, SCHD BTN, BLK, ZN
102 1 MR-18402 Motor, Elevation, 115 VAC
102 1 MR-18403 Motor, Elevation, 230 VAC
103 1 MR-18214 Motor, Drive, 115 VAC
103 1 MR-18215 Motor, Drive, 230 VAC
111 1 AF-19194 Weldment, Monitor Bracket, 425T
120 1 EH-19416 Heat Sink, Silpad
121 1 EC-15004 Ferrite, Clamp-on, .40 I.D.
200 1 AX-18765 Assembly, Top Platform, Right
201 1 AX-18764 Assembly, Top Platform, Left
202 1 AF-18486 Weldment, Upright
203 1 AF-18461 Weldment, Frame, 425T
204 1 DE-18766 Decal, Safety Walk
205 8 HS-15706 Screw, 8-16 x .50, PNHD, STL, BLK ZN CLR, TYP WB
206 1 PL-18931 Cover, Rear, Top Left
207 1 PL-19120 Cover, Rear, Bottom Left
208 1 PL-18928 Cover, Rear, Top Right
209 1 PL-19118 Cover, Rear, Bottom Right
210 1 DE-19441 Decal, 425T, Black
210 1 DE-19442 Decal, 425T, Silver 877
211 1 HX-18287 Plug, Hole, Plastic, 1”, Black
300 1 AX-18545 Assembly, 425T Console
301 1 AX-19356 Assembly, Cover, Top CHR
304 1 AD-18207 PCA, Display, 425T
305 1 AF-19187 Bracket, Console Anchor, Right
306 1 AF-19188 Bracket, Console Anchor, Left
308 1 DE-18556-4 Decal, Warning, Right
309 1 DE-18557-4 Decal, Warning, Left
310 1 EC-17877 Sensor, Polar Wireless Remote Mount
311 4 HS-15706 Screw, 8-16 x .50, PNHD, STL, BLK ZN CLR, TYP WB
312 7 HS-41187 Screw, SLFTP, 8-16 x .3125, Plastite
313 1 HX-17788 Tape, Double Sided, .032 Thick
314 2 PL-17686 Tab, Book Holder
315 1 PL-18548 Console, Plastic, 425T
316 1 SW-18520-4 Membrane, 425T, Top, English
317 1 SW-18523-4 Membrane, 425T, Bottom, English
318 1 DE-19189-4 Label, Warning
402 1 AX-19193-4 Assembly, TV Support
403 1 FS-19190 Controller Mount
404 1 HS-19369 Screw, 1/4-20 x 1.25”, PHL, PAN, BLK ZINC
405 1 HW-00180 Washer, Split Lock 1/4”
