Cybex 425T Treadmill Service Manual
ITEM QTY. PART NO. DESCRIPTION
NO.
406 1 HS-41006 Screw, 10-24 x 1/2”, RECESS, PAN HD, TT, SS
407 1 HS-11977 Screw, SEMS, 8-32 x .38”, PNHD PHIL, EXT, STL, BLK ZN
NS 1 AF-19068 Bracket, Power Factor
NS 1 AW-19117 Cable, A/V Option
NS 1 AW-18216 Cable, Harness, Console
NS 1 AW-18256 Cable, Polar Jumper
NS 1 AW-18528 Cable, Harness, Frame
NS 1 AW-18530 Cable, Filter to Board, Hot, Black
NS 1 AW-18531 Cable, Filter to Board, Neutral, White
NS 1 AW-18532 Power Cord, 115 VAC
NS 1 AW-18533 Power Cord, 230 VAC
NS 1 AW-18534 Power Cord, 230 VAC, 50 Hz
NS 1 AW-19525 Power Cord, 230 VAC, UK
NS 1 AW-18540 Cable, Circuit Breaker to Filter, Hot, Black
NS 1 AW-18541 Cable, Circuit Breaker to Filter, Neutral, White
NS 1 AW-18574 Cable, Speed Signal
NS 1 AW-18972 Cable, Elevation Motor
NS 1 AW-19221 Cable, Contact Heart Rate Grip and Ground
NS 1 AW-19235 Cable, Control Board, Ground
NS 1 AX-19193 Controller Mount
NS 1 AX-19354 Kit, Install Hardware
NS 1 DE-18413 Decal, ETL
NS 1 CN-17687 Adapter, 1/4 Plug to 1/8 Jack
NS 4 EH-10291 Wire Tie, Base
NS 1 EH-19220 Jacket, Corrugated Tubing, 27 Long
NS 1 FS-17698 Clamp, Headphone Adapter
NS 1 FS-19190 Controller Mount
NS 1 FS-18771 Cover, Lower, Motor Controller
NS 4 HS-19108 Screw, 5/16-18 x 3/4, LG HXHD, Whiz Lock, GR5
NS 2 HS-19369 Screw, 1/4 - 20 x 1.25, PNHD PHIL, Black Zinc
NS 1 HX-19059 Plug, Tube End, 1.5 O.D.
NS 1 LT-03051 Sign Facility Safety
NS 1 LT-19339 Warranty Sheet, 425T
NS 1 LT-19340 Poster, Installation
NS 1 LT-19431-4 Owner’s Manual, 425T
NS 1 SK-18553 Kit Brush, McMillan 3.0HP 110V
NS 1 SK-18554 Kit Brush, McMillan 3.0HP 220V
NS 2 TR-19201 Choke
NOTE: NS = Not Shown
Service
Page 4-38
