CYBEX LCX-425T

Cybex 425T Treadmill Service Manual
Service
Page 4-36
Parts List
ITEM QTY. PART NO. DESCRIPTION
NO.
1 1 AF-18899 Weldment, Console Back Plate
2 1 AL-18596 Front Roller, 2.75 O.D.
3 1 AL-18597 Rear Roller, 2.75 O.D.
6 1 AX-17578 Assembly, Contact Grip, Pair
7 1 AF-18394 Weldment, Elevation
8 1 AX-18729 Assembly, Idler
9 1 AX-19150 Assembly, E-Stop Lanyard
10 1 AX-19239 Assembly, Motor Cover
11 1 BD-18763 Belt, Running
12 1 BD-18917 Belt, Poly-V,320J8
15 2 DE-19360 Decal, Side Labels, Black
15 2 DE-19353 Decal, Side Labels, Silver
17 1 DK-18401 Deck, Running
18 1 EC-18573 Sensor, Speed
19 1 EH-00986 Wire Tie, 9”
20 1 EH-10291 Base, Wire Tie
21 1 FM-18405 Shaft, Elevation
22 4 FS-16511 Plate, Rear Rubber Foot Mounting
23 1 FS-19213 Cable, Connector Plate, 425T
24 1 FT-16825 Sleeve, Elevation Mounting, Top
25 1 FT-16826 Sleeve, Elevation Mounting, Bottom
26 2 HB-16367 Bushing, .50 I.D. x .62 O.D. x .31 LG, Flanged
27 2 HN-10029 Nut, 1/2 - 13 HEX STL ZINC
28 2 HN-17935 Nut Locking, 3/8 - 24, GRD C, STL, ZN
29 2 HS-00156 Screw, 4-40 x .62, PNHD PHIL
30 2 HS-00261 Bolt, 1/2 - 13 x 5.5, HXHD
31 6 HS-15706 Screw, 8-16 x .50, PNHD, STL, BLK ZN CLR, TYP WB
32 10 HS-16509 Screw, SLFTP, 10 x .5, PNHD, PLT, TYP B, PT-S
33 10 HS-16628 Bolt, 1/4 - 20 x 1.5, HXHD, G8
34 6 HS-16929 Bolt, Whiz Lock, 3/8 - 16 x .625, HXHD, G5
35 8 HS-16939 Screw, SEMS,10/32 x .75, PNHD, BLK ZN, EXT
36 1 HS-17936 Bolt, 3/8 - 24 x 2.0, HXHD CAP, G8, YEL ZN
37 1 HS-17937 Bolt, 3/8 - 24 x 2.75, HXHD CAP, G8, YEL ZN
38 4 HS-19108 Screw 5/16-18 x 3/4, HXHD, Whiz-Lock
39 1 HS-41006 Screw, SLFTP, 10/24 x 1.38, PNHD PHIL, SST, BLK, TT
40 2 HS-41107 Bolt, 5/16 - 18 x 1.5, BTHD, SST, BLK
41 2 HW-00165 Washer, Split Lock, 5/16, ZINC
42 8 HW-00180 Washer, Split Lock, 1/4, SST, BLK
43 2 HW-00590 Bushing, Nylon, 1/2
44 12 HW-18123 Washer, .344 I.D. x .75 O.D. x .125 Thick, Black Zinc
45 2 HX-13771 Ring, Retaining, 5/8 x .579 FR. I.D.
46 2 HX-15678 Bushing, Deck, 5/16 - 18
47 1 HX-17711 Plug, Plastic, 7/16, BLACK
48 4 HX-17788 Tape, Double Sided, .032 Thick
49 2 HX-18133 E-Ring, Retaining, 5133-37
50 2 HX-18901 Grips, 425 Upright Handrail
51 1 HX-19052 Idler Spring
52 2 HX-19102 Rubber Foot, Rear
53 1 HX-19384 Coupling, Shaft, DBL Split 5/8
56 1 PL-18773 Plunger, E-Stop
57 1 PL-18929 Cover, Rear, Outer Right
58 1 PL-18930 Cover, Rear, Inner Right
59 1 PL-18932 Cover, Rear, Outer Left
60 1 PL-18933 Cover, Rear, Inner Left
61 1 PL-18990 Cover, Motor, Front, 425T
62 1 PL-18991 Cover, Motor, Right ,425T
63 1 PL-18992 Cover, Motor Left,425T
64 1 PL-19061 Cover, Console, Back Trim, 425T
65 1 PL-19093 Cover, Handle Lower
66 1 PL-19094 Accessory Tray, 425T Console
68 1 SW-18535 Switch, Limit
70 8 HS-11977 Screw, SEMS, 8/32 x .38, PNHD
74 2 CW-16712 Wheel, 3 Dia. x 1.25 W, Plain Bearing
