10/100 Fast Ethernet Switch User’s Guide
Identifying External Components 11
33
3 IDENTIFYING
EXTERNAL
COMPONENTS
This chapter describes the front panel, rear panel and LED
indicators of the Switch
Front Panel
The front panel of the Switch consists of 8 (10/100 Mbps) MDI-X
ports, 1 uplink (MDI-II) port, a RS-232 communication port and
LED indicators.
Figure 3-1. Front panel view of the DES-3208 Switch
♦ 8 high performance N-way (MDI-X) ports all operating at
10/100 Mbps for connection to servers and hubs. All ports
can be auto-negotiated between 10Mbps or 100Mbps.
