10/100 Fast Ethernet Switch User’s Guide
54 Using the Console Interface
Port Configuration
The port configuration menu allows you to change the port state
in the case when you would like to partition a port due to
excessive collision, or for observation, device repair, security
reasons. Great caution, however, must be observed when
partitioning a port; you should make sure that the partitioned port
is not being used as the port to control or monitor the condition of
other devices.
To change the configuration of a port:
1. Choose Port Configuration from the main menu.
2. Specify the port in the Port(1-8) field.
3. In the Port State field, change the port state to enable or
disable.
4. Choose SAVE and press Enter to let the changes take effect.
5. Choose EXIT and hit the enter key to leave the Port
Configuration menu.
Figure 6-16. Port Configuration Menu
