10/100 Fast Ethernet Switch User’s Guide
72 RJ-45 Pin Specification
BB
8 RJ-45 PIN
SPECIFICATION
When connecting the DES-3208 Switch to another switch, a bridge
or a hub, a modified crossover cable is necessary. Please review
these products for matching cable pin assignment.
The following diagram and table show the standard RJ-45
receptacle/connector and their pin assignments for the switch-to-
network adapter card connection, and the straight/ crossover cable
for the Switch-to-switch/hub/bridge connection.
Figure B-1. The standard RJ-45 receptacle/connector
