10/100 Fast Ethernet Switch User’s Guide
Connecting The Switch 19
10Base-T Hub
For a 10 Base-T hub, the Switch’s LED indicators should
illuminate the following:
♦ 100M LED speed indicator is OFF.
♦ Link/Act indicator is ON.
♦ FDX/Col indicator is OFF.
100Base-TX Hub
For a 100Base-TX hub, the Switch’s LED indicators should
illuminate the following:
♦ 100M LED speed indicator is ON.
♦ Link/Act is ON.
♦ FDX/Col LED indicator is OFF.
Hub without Uplink (MDI-II) port
If a hub is not equipped with an uplink (MDI-II) port, then
connection can be made using either straight cable or crossover
cable (see Appendix A, Technical Specifications for cable
requirements).
