10/100 Fast Ethernet Switch User’s Guide
70 Technical Specifications
General
Network Cables: 10BaseT:
2-pair UTP Cat. 3,4,5 (100 m)
EIA/TIA- 568 100-ohm STP (100 m)
100Base-TX:
2-pair UTP Cat. 5 (100 m)
EIA/TIA-568 100-ohm STP (100 m)
Number of Ports: 8 x 10/100 Mbps NWay ports
Media Interface
Exchange:
MDI-II RJ-45 shared with port 1x
Controller Chips VLSI
Physical and Environmental
AC inputs: 100 - 240 VAC, 50/60 Hz (internal universal power supply)
Power Consumption: 40 watts maximum
DC fans: 2 built-in 40x40 mm fan
Operating
Temperature:
0 ~ 50 degrees Celsius
Storage Temperature: -40 ~ 70 degree Celsius
Humidity: 5% ~ 95% non-condensing
Dimensions: 324x231x43 mm (1U), 19 inch rack-mount width
Weight: 3 Kg
