10/100 Fast Ethernet Switch User’s Guide
74 MII Connector Specifications
CC
9 MII CONNECTOR
SPECIFICATIONS
The MII (Media Independent Interface) is a 40 pin connector used
for making connection with other LAN networks. This connector
has a shared connection with port 2x, and when connected, the
MII connection takes operational precedence over port 2x.
The following Figure and table show the standard MII 40 pin
connector and the pin assignment.
Figure C-1. The Standard MII connector
