10/100 Fast Ethernet Switch User’s Guide
MII Connector Specifications 75
MII Connector Pin Assignment
Contact MII
Signal
Signal Name Contact MII
Signal
Signal Name
1 +5 V Voltage 21 +5 V Voltage
2 MDIO MAC Data
Input Output
22 --- Ground
3 MDC MAC Data
Clock
23 --- Ground
4 RXD<3> Receive Data 3
bit
24 --- Ground
5 RXD<2> Receive Data 2
bit
25 --- Ground
6 RXD<1> Receive Data 1
bit
26 --- Ground
7 RXD<0> Receive Data 0
bit
27 --- Ground
8 RX_DV Receive Data
Valid
28 --- Ground
9 RX_CLK Receive Clock 29 --- Ground
10 RX_ER Receive Error 30 --- Ground
11 NOT
USED
Not Used 31 --- Ground
12 TX_CLK Transmit Clock 32 --- Ground
13 TX_EN Transmit
Enable
33 --- Ground
14 TXD<0> Transmit Data 0
bit
34 --- Ground
15 TXD<1> Transmit Data 1
bit
35 --- Ground
