DGS-3100 Series Gigabit Stackable Managed Switch Hardware Installation Guide
Powering on the Device
The device can be used with AC power supply 100-240 VAC, 50 - 60 Hz. The device’s power supply adjusts to the local
power source automatically, and can be powered on without having any or all LAN segment cables connected.
After the device is plugged in:
All LED indicators, except console, momentarily flash. Flashing LEDs indicate the system is being reset.
The console LED indicators flash while the device loads software and performs a self-test. When the POST is
passed, the LED darkens. If the POST fails, the LED lights solid amber. This indicator lights solid green when the
device is being logged-in via a local console management port (RS-232) using a straight-through serial cable.
CAUTION: In the event of a power failure, unplug the device. When power is resumed, plug the device
back in.
14

Table of Contents

Other manuals for D-Link DGS-3100 SERIES

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the D-Link DGS-3100 SERIES and is the answer not in the manual?

D-Link DGS-3100 SERIES Specifications

General IconGeneral
TypeManaged
LayerLayer 2+
Ports10/100/1000BASE-T
SFP Ports2 or 4 (depends on the model)
Additional SFP PortsNo
VLANsYes
StackingYes, Physical Stacking
QoSYes
Jumbo Frame SupportUp to 9K bytes
ManagementWeb-based
Operating Temperature0°C to 40°C
Humidity10% to 90% non-condensing
Standards ComplianceIEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.1Q, IEEE 802.1p
ModelDGS-3100 SERIES
Storage Temperature-40°C to 70°C
