D-Link DGS-3100 SERIES Hardware Installation Guide

DGS-3100 Series Gigabit Stackable Managed Switch Hardware Installation Guide
40
A
DEVICE SPECIFICATIONS
This appendix contains the device specifications, and contains the following topics:
• Technical Specifications
• Cable Lengths
Technical Specifications
Performance
Transmission Method
Store-and-forward
RAM Buffer
512Kbytes per device
Packet Filtering/ Forwarding Rate
Full-wire speed for all connections.
1,488,095 pps per port (for 1000Mbps)
MAC Address Learning
Automatic update. Supports 8K MAC address.
Priority Queues
4 Priority Queues per port.
Forwarding Table Age Time
Max age: 0–630 seconds.
Default = 300.
Physical and Environmental
AC Inputs
100 – 240 VAC, 50/60 Hz (internal universal power supply)
Power Consumption
1) DGS-3100-24P: 126W (For system power)
370W (For POE power)
2) DGS-3100-24: 60W
3) DGS-3100-48P: 126W(For system power)
370W(For POE power)
4) DGS-3100-48: 139.5W
5) DGS-3100-24TG - 60W
DC Fans
2 built-in 40 x 40 x 10 mm fans
Operating Temperature
0 to 40 degrees Celsius (32 to 104 degrees Fahrenheit)
Storage Temperature
-40 to 70 degrees Celsius (-40 to 158 degrees Fahrenheit)
Humidity
Storage: 5% to 95% non-condensing
Dimensions
441mm (W) x 309mm (D) x 44mm (H), 19-inch rack-mount width 1U
height
Weight
3.8 kg (8.38 lb)
EMI
FCC, CE Mark
Safety
CSA International
General
Standards
IEEE 802.3 10BASE-T Ethernet
IEEE 802.3u 100BASE-TX Fast Ethernet
IEEE 802.3z Gigabit Ethernet

D-Link DGS-3100 SERIES Specifications

General

Type	Managed
Layer	Layer 2+
Ports	10/100/1000BASE-T
SFP Ports	2 or 4 (depends on the model)
Additional SFP Ports	No
VLANs	Yes
Stacking	Yes, Physical Stacking
QoS	Yes
Jumbo Frame Support	Up to 9K bytes
Management	Web-based
Operating Temperature	0°C to 40°C
Humidity	10% to 90% non-condensing
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.1Q, IEEE 802.1p
Model	DGS-3100 SERIES
Storage Temperature	-40°C to 70°C
