D-Link DGS-3100 SERIES Hardware Installation Guide

DGS-3100 Series Gigabit Stackable Managed Switch Hardware Installation Guide
41
General
IEEE 802.1Q Tagged VLAN
IEEE 802.1P Tagged Packets
IEEE 802.3ab 1000BASE-T
IEEE 802.3x Full-duplex Flow Control
ANSI/IEEE 802.3 NWay auto-negotiation
Protocols
CSMA/CD
Data Transfer Rates
Ethernet:
Fast Ethernet:
Gigabit Ethernet:
Half-duplex Full-duplex
10 Mbps 20 Mbps
100 Mbps 200 Mbps
2000 Mbps (Full duplex only)
Topology
Star
Network Cables
10BASE-T:
UTP Category 3, 4, 5 (100 meters max.)
EIA/TIA- 568 150-ohm STP (100 meters max.)
100BASE-TX:
UTP Cat. 5 (100 meters max.)
EIA/TIA-568 150-ohm STP (100 meters max.)
1000BASE-T:
UTP Cat. 5e (100 meters max.)
UTP Cat. 5 (100 meters max.)
EIA/TIA-568B 150-ohm STP (100 meters max.)
1000BASE-LX:
Single-mode fiber module (10km)
1000BASE-SX:
Multi-mode fiber module (550m)
100BASE-FX:
Fast Ethernet Single Mode fiber module (2km)
Mini-GBIC:
SFP Transceiver for 1000BASE-LX
Single-mode fiber module (10km)
SFP Transceiver for 1000BASE-SX
Multi-mode fiber module (550m)
SFP Transceiver for 100BASE-FX
Single-mode fiber module (2km)
Number of Ports:
DGS-3100-48/P - 48 x 10/100/1000 Mbps ports + 4 x GBIC ports
DGS-3100-24/P – 24 x 10/100/1000 Mbps ports + 4 x GBIC ports
DGS-3100-24TG - 8 x 10/100/1000 Mbps ports + 16 x GBIC ports

D-Link DGS-3100 SERIES Specifications

General

Type	Managed
Layer	Layer 2+
Ports	10/100/1000BASE-T
SFP Ports	2 or 4 (depends on the model)
Additional SFP Ports	No
VLANs	Yes
Stacking	Yes, Physical Stacking
QoS	Yes
Jumbo Frame Support	Up to 9K bytes
Management	Web-based
Operating Temperature	0°C to 40°C
Humidity	10% to 90% non-condensing
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.1Q, IEEE 802.1p
Model	DGS-3100 SERIES
Storage Temperature	-40°C to 70°C
