DGS-3100 Series Gigabit Stackable Managed Switch Hardware Installation Guide
42
Cable Lengths
Use the following table to as a guide for the maximum cable lengths:
Standard Media Type Maximum
Distance
Mini GBIC
DEM-310GT: SFP Transceiver for 1000BASE-LX, Single-mode fiber
module
10km
DEM-311GT: SFP Transceiver for 1000BASE-SX, Multi-mode fiber module 550m
1000BASE-TT
Category 5e UTP Cable
Category 5 UTP Cable
(1000 Mbps)
100m
100BASE-TX
Category 5 UTP Cable (100 Mbps) 100m
10BASE-TTTT
Category 3 UTP Cable (10 Mbps) 100m
