131
Frequently Asked Questions (continued)
Step 4 Click on Policy and verify that
you have an Outgoing policy configured.
If not, click on New Entry, accept the
default values, and click OK.
Step 5 Click on VPN and then click
New Entry.
Step 6 Give the VPN connection a name with no spaces.
Step 7 Enter the network identifier and subnet mask of the Internal interface.
Step 8 In the To Destination section, select either Remote Gateway—Fixed IP or
Remote Gateway—Dynamic IP. Enter the WAN IP address of the DI-808HV if Remote
Gateway—Fixed IP is selected.
Step 9 Enter the network identifier corresponding subnet mask of the DI-808HV´s LAN.
Step 10 Enter a Preshared Key. The Preshared Key needs to be identical to the one
configured on the DI-808HV
Step 11 Select Data Encryption and Authentication as the Encapsulation and click
OK.
How can I set up my DI-808HV to work with a DFL-300 Firewall?
(continued)
