4D-Link DIR-615 User Manual
Section 1 - Product Overview
Hardware Overview
Connections
1 LAN Ports (1-4) Connect Ethernet devices such as computers, switches, and hubs.
2 Internet Port
Connect your DSL, cable modem or other Internet connection here to provide Internet connectivity to
the router.
3 Power Receptor Receptor for the supplied power adapter.
4 Reset Pressing the Reset button restores the router to its original factory default settings.
2 3 41
