4D-Link DVA-5592 User Manual
Section 1 - Product Overview
Hardware Overview
Front Panel
1 USB Ports USB port, for connecting a 3G/4G dongle or other USB storage devices.
2 WPS Button Press for 1 second to enable WPS pairing.
3 WLAN Button Press to toggle Wireless radios.
4 Power
Green
O Power is o.
On System startup is complete.
Orange On Power failure.
5 WAN Green
O No signal detected.
Blinking Initializing DSL.
On DSL Online.
6 Internet
Green
O
Either the device is in Bridge Mode, the DSL connection is not present, or the power is
o.
Blinking Internet data is being transmitted.
On An Internet connection is established.
Orange On The device attempted an Internet connection, but failed.
4 5 62 3 71 8 9 10
