DVG-5402G/GF Wireless AC1200 MU-MIMO Dual Band
Gigabit Router with Fiber WAN Port, 3G/LTE Support, 2 FXS
Ports, and USB Port
User Manual
Configuring via Web-based Interface
Figure 113. The page for adding a GRE tunnel.
You can specify the following parameters:
Parameter Description
Enable
Move the switch to the right to enable the GRE tunnel.
Move the switch to the left to disable the GRE tunnel.
Tunnel settings
Name
A name of the tunnel for easier identification. You can specify any
name.
IP address
The IP address of the GRE tunnel interface.
Mask
The mask of the subnet.
Interface
From the drop-down list, select a WAN connection through which
the tunnel will pass. Select the Default gateway value to use the
default WAN connection.
Page 139 of 311
