DVG-5402G/GF Wireless AC1200 MU-MIMO Dual Band
Gigabit Router with Fiber WAN Port, 3G/LTE Support, 2 FXS
Ports, and USB Port
User Manual
Configuring via Web-based Interface
Parameter Description
Action
Select an action for the rule.
• Allow: Allows packet transmission in accordance with the
criteria specified by the rule.
• Deny: Denies packet transmission in accordance with the
criteria specified by the rule.
Protocol
A protocol for network packet transmission. Select a value from the
drop-down list.
IP version
An IP version to which the rule will be applied. Select the relevant
value from the drop-down list.
Direction
The direction of network packet transmission to which the rule will
be applied. Select the relevant value from the drop-down list.
• LAN to WAN: The rule will be applied to the packets
transmitted from the local network to the external network.
• WAN to LAN: The rule will be applied to the packets
transmitted from the external network to the local network.
• LAN to Router: The rule will be applied to the packets
transmitted from the local network to DVG-5402G/GF.
• WAN to Router: The rule will be applied to the packets
transmitted from the external network to DVG-5402G/GF.
Source IP Address
Set as
Select the needed value from the drop-down list.
Start IPv4 address /
Start IPv6 address
The source host start IPv4 or IPv6 address.
If it is necessary to specify a single address, leave the End IPv4
address / End IPv6 address field blank.
You can choose a device connected to the router's LAN at the
moment. To do this, select the relevant IPv4 or IPv6 address from the
drop-down list (the field will be filled in automatically).
End IPv4 address /
End IPv6 address
The source host end IPv4 or IPv6 address.
Subnet IPv4 address /
Subnet IPv6 address
The source subnet IPv4 or IPv6 address. The field is displayed when
the Subnet value is selected from the Set as drop-down list.
Destination IP Address
Set as
Select the needed value from the drop-down list.
