(1) Charging State Indicator
417O823A
TO RECOGNIZE THE CHARG-
ING CONDITIONS.
Exchange or recharge the battery
according to the charging state.
[Charging state]
Normal
Need to be
charged
Need to
exchange
Green Black White
When it is difficult to start
the engine or lights are get-
ting dimmer, charge the bat-
tery immediately.
When installing or remov
-
ing the battery, do not tilt
or hold the battery upside-
down. If you do so, the elec-
trolyte may leak.
•
•
CAUTION
CHARGING THE BATTERY
Recharging the battery should be
done after you take the battery out
of the combine. Otherwise, you
may damage electric parts or wir-
ing.
Connect the positive (+) charging
cable to the positive (+) terminal
of the discharged battery and the
negative (-) cable to the negative
(-) terminal of the battery. Charge
it in a normal way.
If you recharge the battery in a
quick way with a large current,
charge the battery again after the
intended operation.
