417O866A 417O867A
1. If the ch ain is too much
loose to adjust its tension,
mm) from the chain.
2. Set up the left and right el
-
evating rakes as shown in
the figure so that they will
not collide when they are
raised up inside of the reap-
ing unit.
3. If improperly adjusted, they
will be broken.
CAUTION
417O865A
The ‘a’ rakes should be placed between
the ‘b’ rakes.
If the chain is to o much
loose to adjust its tension,
mm) from the chain.
•
CAUTION
If the chain is to o much
loose to adjust its tension,
mm) from the chain.
•
CAUTION
EAR SIDE FEEDING CHAIN
(1) Stopper
(A) Adjust the stopper to cover the slit
The tension of the chain will auto-
matically be adjusted by its spring.
When the tension becomes loose
or the slit becomes visible, move
to the stopper to let the slit and
shaft can slightly touch each other.
(1) Plant Side Chain (Right)
(A) 168~172 mm
The length of
spring when at
-
tached (A)
168 ~ 172 mm
To Next Page
