417O877A
Oil
DAEDONGTF55
Capacity
10
ℓ
(1) Oil Filler Cap (2) Oil Gauge
(A) The appropriate range.
[Replenishing Oil]
Tighten up the drain plug and pour
an appropriate amount of oil into
the oil ller hole. Then tighten up
theoilllercaptoo.
Remove the drain plug at the bot-
tom of the transmission case to
drain the old oil. After draining it
completely, tighten up the plug
and replenish the transmission oil.
If the oil comes out through the
checking bolt when it is loose, it
is the appropriate oil level. Then,
tighten the checking bolt (M8).
(1) Drain Plug (3) Oil Filler Cap
(2) Bolt for Checking Oil
CHANGING THE TRANSMIS-
SION OIL
Because this transmission
oil is also used as the brake
fluid, do not use any other
types of oil.
•
CAUTION
