8-50 DSC62
If the replaced fuse blows
u p i m m e d i a t e l y, d o n o t
replace with other metal
wires. Contact a near dealer
and have the combine ser-
viced.
•
CAUTION
417O880A
417O879A
Preheating
controller /
timing relay
For
customer
only
Working
lamp
Headlight
/ taillight
Spare Spare
Spare Spare
Spare fuse
Stop
light
Direction
indicator /
Horn
Fuse
box
Part No.
Use only the fuse of rated capacity
timing
relay
Drain oil by unplugging the drain
plug located at the left bottom of
the transmission case. After drain-
ing, close the drain plug and add
oilthroughthellerhole.
(1) Oil Filler Cap (4) Hydraulic Oil Filter
(2) Oil Checking Bolt (5) Drain Plug
(3) Oil Tank
CHANGING THE HYDRAULIC
OIL IN THE OIL TANK
(1) Fuse Box
CHANGING THE FUSES
CHANGING THE FUSES
1. Open the fuse box.
2. remove the fuse.
3. Replace the blown fuse with a
new one of the same capacity.
Oil Capacity
DAEDONG
TF55
22
ℓ
417O881B
