8-54 DSC62
Change the oil when you
change the cartridge.
•
CAUTION
1
417O888A 417O889A
1. Remove the drai n plug and
drain the oil tank.
2. Remove the old oil filter car-
tridge.
3.Install a new oil lter cartridge.
(Apply a thin layer of oil on the
ltergasket.)
4. The oil filter cartridge should
be replaced after the initial 50
hours. After the first change,
replace it every 200 working
hours.
(1) HST Oil Filter
CHANGING THE HST AND
HYDRAULIC OIL FILTERS
(1) Oil Filler Cap (4) Hydraulic Oil Filter
(2) Oil Checking Bolt (5) Drain Plug
(3) Oil Tank
417O890A
CHANGING THE STRAW
CUTTER BLADE
1. Remove the drive belt
2. Remove the 180 pulley.
(1) Drive Belt (3) M10 Bolt
(2) 180 Pulley
