Daedong DSC62 - Page 156

8-58 DSC62
Drawing
number
Part number Part name
1
2
3
4
5
6
7
8
9
10
11
12
57781-5241-1
C7340-52421
57666-5223-1
57704-5222-1
57781-5258-1
57781-5261-2
57781-5245-1
57781-5257-1
57781-5246-1
57781-5256-1
57781-5247-1
C7340-52481
Cutting shaft
Shaft handle 1
Shaft handle spacer 1
Anti-roll drum
Support washer 3
Cutter blade 170
Pipe-58.9
Support washer 2
Anti-roll wheel 2
Spring washer 20
Hex. nut (LH)
Shaft handle 2
1
1
1
1
1
16
14
1
1
1
1
1
(1) M8 Bolt
(2) M16 Nut
(A) Left rotation: To narrow the clearance
(B) Right rotation: To widen the clearance
417O897A
