417O610A
(1) Main Shift Lever (2) Aux. Shift Lever
417O609A
6. To adjust your direction, gently
push the steering lever to the
right or left.
7. Depress the parking brake ped-
al to release the brake.
(1) Parking Brake (3) Arrester
(2) Parking Brake Pedal (A) Release
8. Select a proper driving speed
with the auxiliary shift lever.
9. Slowly push the main shift lever
to FORWARD to move forward.
If you pull the lever to BACK-
WARD, the combine will back-
ward.
Main shift lever
Aux. shift lever
Do not attempt a sharp turn
on a gravelly road. Gravels
may get stuck in the crawl-
ers and cause malfunctions.
Before shifting the auxiliary
shift lever, you must engage
the main shift lever to STOP.
Keep the engine speed 2,000
rpm or above during driv-
ing.
Be careful that the reaping
unit may fall down if you
leave it at a lifted position
for a long time.
•
•
•
•
CAUTION
A Forward
B Stop
C Backward
D Low Speed
E Neutral
F Standard
G High Speed
To Next Page
