(1) Standard Position
(A) Lower
A D j U S T I N G T H E C U T T E R
BLADE HEIGHT
Set the cutter blade lower if you
want to lower the cutting height.
417O715A
ditch.
•
CAUTION
(1) Slide Rail
(A) HIGH (B) LOW
ADjUSTING ELEVATOR RAKE
HEIGHT
1. Adjust the elevator rake height
to be lower than height of crop
ear when the ear is easy to sep-
arate. There are 4 different rake
heights.
2. Adjust the elevator rake height
to the higher position when har-
vesting tall or lodged crop.
417O716A
•
CAUTION
To Next Page
