(1) Elevator Rake Cover
(2) Bolt
3. To remove the elevator rake
cover, unbolt the cover and de-
tach them from the reaping unit.
4. Adjust the slide rails.
(1) Elevator Rake Guide (Right) - Standard
Position
(2) Nut
E L E V A T O R R A K E G U I D E
Adjust the guide to reduce any
grain loss.
As shown in the gure above, un-
bolt the two nuts under the eleva-
tor rake guide and push the guide
to the arrowed direction. Then, x
it with the nuts.
