2. When the hopper and grain
sacks are full, all grain lamps on
the service alert panel will icker
and a horn will be blown.
(1) Grain Lamp
417O743A
4. After pushing the shutter to the ar-
rowed direction, take out the lled
grain sacks below the hopper.
5. Then, hang new sacks on the
grain sack hangers under the hop-
per and open the shutters again to
discharge the grain from the hop-
per.
6. If the new sacks are full, take them
out. And connect new sacks to the
hangers. Repeat these steps until
the hopper is empty.
(1) Shutter
(A) Push (B) Pull
(1) Threshing Clutch Lever
(A) Disengage
3. When a alert sound, immediate-
ly stop reaping and discharge
grains in the hopper.
•
CAUTION
417O744A 417O745A
To Next Page
