Front Wheel/Front Fork/Steering
NOTE
● Remove the dust seal.
● Remove the set ring.
● Remove the oil seal.
NOTE
12-11
If the socket bolt turns idle but cannot be
removed, temporarily assemble the spring and
the fork tube cap bolt first.
Hold the bottom case firmly with a vise, taking
precautions not to distort or damage it.
Take precautions not to damage the interior and
exterior rim of the bottom case.
Dust seal
Bracket
Vise
Set ring
To Next Page
