Pilot's Operating Handbook
Section 7
Description
Edition 0 - October 31, 2013
TR29 - July 2022
Page 7.3.26
Emergency exit - se
e figure 7.3.10
The emergency exitis installed on the right side ofthe fuselageandopens towardsthe
inside. It is equipped with two handles, one inside and the other outside, each located
on the upper frame.
When the airplane is parked, the closing system may be locked by a safety pin
provided with a flag marker. The handle is then inoperable.
▲ WARNING ▲
Taxiing and flying with thief-proof safety pin installed is
forbidden.
▲
To open the emergency exit, pull one of the two handles and tilt the emergency exit
fro
m top to bottom towards inside of airplane.
>> Pre-MOD70-0793-25
▲ CAUTION ▲
Before opening the emergency exit from the inside of the airplane,
remove the upholstery panel of the emergency exit.
Using the two hands, pull firmly the upholstery panel through the
access area to the opening handle - see figure 7.3.10A.
▲
>> All
