Daher TBM 900 - Fuel System

Pilot's Operating Handbook
List of equipment
Edition 0 - October 31, 2013
Rev. 5
Page 17
S/
R/
A/
O
A
rm
in.
(m)
Weight
per unit
lb
(kg)
Required (R) or Standard (S) or Optional (A or O)
equipment
Item
OPT70
or
MOD70
28 - Fuel system
28-20 - Fuel supply
R Electric boost pump 1B9-5 4.409
(2.000)
129.92
(3.300)
R Engine driven fuel pump 1127-02 1.543
(0.700)
110.24
(2.800)
R Fuel unit L88A15-651 4.586
(2.080)
133.07
(3.380)
R A35 fuel sequencer unit 1.102
(0.500)
125.98
(3.200)
28-40 - Fuel indication
R 0158-28C Fuel gage amplifier (in us gal)
738574-1-0
1.08
(0.49)
278.74
(7.080)
R Inboard L.H. gage 762 438.1.0 0.331
(0.150)
183.07
(4.650)
R Inboard R.H. gage 762 439.1.0 0.331
(0.150)
183.07
(4.650)
R Intermediate gage 762 440.1.0 0.220
(0.100)
190.94
(4.850)
R Outboard gage 762 441.1.0 0.220
(0.100)
190.94
(4.850)
R Low level sensor 722-447 0.110
(0.050)
183.07
(4.650)
PIM - DO NOT USE FOR FLIGHT OPERATIONS
