Daher TBM 900 - Landing Gears

Pilot's Operating Handbook
List of equipment
Edition 0 - October 31, 2013
Rev. 5
Page 20
S/
R/
A/
O
A
rm
in.
(m)
Weight
per unit
lb
(kg)
Required (R) or Standard (S) or Optional (A or O)
equipment
Item
OPT70
or
MOD70
32 - Landing gears
32-10 - Main landing gear
R 0190-32 L.H. main landing gear D23767001 53.79
(24.400)
200.39
(5.090)
R 0190-32 R.H. main landing gear D23768001 53.79
(24.400)
200.39
(5.090)
32-20 - Nose landing gear
R 0134-32 Nose gear D23766000 53.57
(24.300)
93.70
(2.380)
32-30 - Extension and retraction
R Door actuator EC 6230 1.345
(0.610)
192.91
(4.900)
O 0334-32 Main locking actuator VSTS 083560 13.228
(6.000)
208.07
(5.285)
O 0334-32 Nose locking actuator VSTS 083560 13.228
(6.000)
110.24
(2.800)
R Hand pump 914-8D27 2.326
(1.055)
181.10
(4.600)
32-35 - Hydraulic generation
R 060-32 Hydraulic power pack 1118-04 10.362
(4.700)
84.65
(2.150)
32-40 - Wheels and brakes
R Brake assembly 030-19100 14.991
(6.800)
204.33
(5.190)
R Main tire 18x5.5-10PR 13.50
(6.123)
204.33
(5.190)
PIM - DO NOT USE FOR FLIGHT OPERATIONS
