Pilot's Operating Handbook
List of equipment
Edition 0 - October 31, 2013
Rev. 5
Page 27
S/
R/
A/
O
A
rm
in.
(m)
Weight
per unit
lb
(kg)
Required (R) or Standard (S) or Optional (A or O)
equipment
Item
OPT70
or
MOD70
- Transmitting antenna S67-2002 0.300
(0.136)
182.09
(4.625)
and
- Receiving antenna S67-2002 0.300
(0.136)
205.83
(5.228)
34-44 - Traffic advisory system
A 0176-00F G1000 TAWS system / /
A 0258-00B TAS system GTS 820, G1000 coupled, of which : 22.53
(10.220)
177.68
(4.513)
- Processor GTS 820 9.92
(4.500)
143.11
(3.635)
- Power amplifier/low noise amplifier GPA 65 1.90
(0.860)
221.42
(5.624)
- Antenna GA 58 (above fuselage) 0.79
(0.360)
230.71
(5.860)
- Antenna GA 58 (under fuselage) 0.79
(0.360)
260.63
(6.620)
34-51 - NAV 1 installation
S VHF GS-NAV antenna DM N4-17N 3.307
(1.500)
401.57
(10.200)
S Receiver
(integrated in the GIA 63W Integrated Avionics Unit
# 1 : refer to ATA 34-28)
/ /
34-52 - NAV 2 installation
S Receiver
(integrated in the GIA 63W Integrated Avionics Unit
# 2 : refer to ATA 34-28)
