Pilot's Operating Handbook
Supplement 47
GARMINGWX70colorweatherradar
Edition 1 - October 31, 2013
Rev. 2
Page 9.47.6
SECTION 7
Des
cription
Information hereafter supplement or replace those of the standard airplanedescribed
insection 7 Description ofthe basicPOH whenthe airplaneisequipped withtheoption
GARMIN GWX 70 color weather radar.
The weather information are displayed only on the MFD.
The controls forthe MFD are located on both the MFD bezel and the MFD control unit.
Figure 9.47.1 (1/2) - GWX 70 weather radar display and controls
1) MFD
2) Radar mode
3) Area of weather display
4) Antenna stabilization status
5) MFD bezels
6) MFD control unit
7) Changes radar range, TILT and bearing
8) Scale for weather display
