Autothrottle mechanical assembly
The aut
othrottle function actuates the THROTTLE by an assembly of rods and levers
permitting to link the GARMIN servo-motor and the potentiometer.
The THROTTLE movements are defined by the servo-motor.
The THROTTLE position is measured by the potentiometer.
The autothrottle controls are integrated withintheAFCS controlpanelwhich is located
above the MFD.
