Dahua Technology ASA1222E-S User Manual

3.5.3.4 Verification Method
The system supports attendance by fingerprint, password, fingerprint or password. Please
select attendance method, and meantime other methods are invalid.
 Fingerprint, only support fingerprint.
 Password, only support password.
 Password or fingerprint, password and fingerprint both are supported.
Step 1. Select Feature>Function>Confirmation, click .
Step 2. Click or to select attendance, click to confirm.
3.5.3.5 System Self Check
It mainly checks FP self-check, display self-check, voice self-check, and key self-check.
Auto Self Check
Auto checks FP self-check, display self-check, voice self-check, and key self-check.
Select Feature>Features>System Self Check>Auto Self Check, click .
Fingerprint Self Check
Step 1. Select Feature>Features>System Self Check>FP Self Check, click .
Step 2. Place fingerprint on collector area, to view if the fingerprint can be shown on
LCD.
Display Self Check
Select Feature>Function>Self Check>Display Check, click .
Screen shows red, green, blue to test screen display.
Voice Self Check
Select Feature>Function>Self Check>Voice Self Check, click .
Check if user can hear voice from the device, and if yes, the system is normal.
Key Self Check
Step 1. Select Feature>Function>Self Check>Key Self Check, click .
Step 2. According to display, click corresponding key to test.

Dahua Technology ASA1222E-S Specifications

General

Type	Basic access control reader
Certification	CE, FCC
Product color	Black
LED indicators	Status
Number of users	1000 user(s)
Access code reader	-
Fingerprint reader	Yes
Authentication type	Password
Keypad number of keys	16
Fingerprint sensor type	Optical
Flash memory	0.08 GB
Display type	TFT
Display diagonal	2.4 \
Maximum resolution	320 x 240 pixels
DC voltage range	5 - 5 V
Power consumption	1000 mA
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	5 - 95 %
Front camera	No

Weight and Dimensions

Depth	120 mm
Width	175 mm
Height	23 mm
Weight	350 g
